steel wire drawing machine Straight Wire Drawing Machine with low
carbon steel wire
Advantage
1. high speed
2. high productivity
3. low noise
4. low cost
Feature:
1. Full immersed lubricant system,transmission by flat belt,
constant tension, low noise, high efficiency.
2. Capstan made by special tool steel
3. PLC control, dual motor, dual inverter, color touchscreen.
4. Special alignment device at final die position, keep wire
verticality and quality, which is good for next process
5. Stepping motor traverse, pitch adjustable, smooth traversing.
6. Protection device for wire disorder; machine auto stops if
mother wire disorder or break.
Our service
- Our engineers are available to install and maintain machine
overseas.
- Customized machine.
- OEM support.
- Fast delivery.
- Moderate price.
- Door to Door service or 24-hour email service.
Electrical:
① The basic function in wire drawing machine is complete; Single
machine is punctual, leftist writers point move, single point,
leftist writers (right) running, stop; Tuning roller tension
adjustment, mould box and roll cooling water regulation.
② the work station complete: total rev, stop, stop, acceleration,
deceleration,
fault indicator, the meter reset
③ Touch screen to finish: mold fitting
(wire), speed setting, the length of the set (fixed-
length automatic parking), jump die set, inching
speed setting, fault, according to the actual running speed
display, lighting switch
Rotational Die Box
① Die rotation, when wire drawing,the die life increased by 15%,
and steel wire surface lubrication powder evenly, drawing speed
increased by 10%.
② Die box can be universal adjustment to ensure that the Angle of
the steel wire drawing
which provides the high quality wire.
Main technical parameter and points
(1) Inlet strength: ≦600 MPa
- Max inlet dia: Ф6.5mm
- Min wire outlet dia: Ф1.5mm
(4) Max compression rate:87%
(5) Max drawing speed:20m/s Normal drawing speed:18m/s
(6) Water consumption and pressure:5m3/h water pressure≥0.25MPa
(7) Air consumption and pressure:1.0m3/h air pressure≥0.6MPa
(8) Motor:
① Main motor:30KW*1+22KW*5 AC motor
② Wire take-up machine:15KW AC motor
