0.4mm - 2.0mm cored welding wire / solid welding Wire Mesh Panel
Welding Machine
automatic welded wire mesh machine factory
- the wire diameter:1.5-2.5mm or 2.5-6mm
- the hole size:20mm(min)
- plc control full automatic
- roll mesh or sheet mesh all is ok
Main machine of Welded Wire Mesh Machine
| Size of mesh (mm) | 6.35-12.7(1/4’’-2/1’’) |
| Width(mm) | 914.4-1219.2(12’’-48’’) |
| Diameter of wire(mm) | 0.45-1.07(BWG25-BWG19) |
| Max. rolled net size (mm) | 120m(400’’) |
| Welding speeding (mesh /minutes) | 75(radia) |
| Power | 380/220V |
| 50-60HZ |
| 50KWAX4 |
| Outside size (mm) | 2350x1820x1700 |
|
| Size of mesh (mm) | 6.35-12.7(1/4’’-2/1’’) |
| Width (mm) | 1219.2-1928.8(48’’-60’’) |
| Diameter of wire | 0.74-1.07(BWG22-BWG19) |
| Max. rolled net size (mm) | 120m(400’’) |
| Welding speeding (mesh /minutes) | 48(radia) |
| Power | 380/220V |
| 50-60HZ |
| 50KWAX6 |
| Outside size (mm) | 3050x1900x1750 |
Specifications for your reference:
- Wire dia:0.4mm-2.0mm
- Mesh size:12.7mm-50.8mm
- Welding width:91.4mm,1219.2mm,1524mm
- Working power:380V 50-60HZ
- Machine size:2350×1820×1200mm
- Weight: 2.5tons
- Welding speed:110 radia
Welding Wire machine Description:
Automatic production line for high speed wire welding is through
the introduction of Swiss SCHLATTER company technology, after
digestion, absorption, and research and development of a device,
mainly composed of pay-off stand, wire frame, a longitudinal bar
straightening device, longitudinal reinforcement traction device,
storage rack, longitudinal reinforcement secondary straightening
device, longitudinal reinforcement stepping feeding device, welding
host, transverse reinforcement automatic feeding device, shearing
machine, mesh network collection device, network transmission of
orbit, it is mainly used for concrete road, building, tunnel,
subway, water conservancy, such as prefabricated steel fabric in
the construction field. This product production efficiency is high,
the annual output can reach 50000 tons.
Features:
1. At present, a lot of other domestic products applicable to weld
straight bar steel, need to manually wear reinforcement, the
intensity of labor is big, the production efficiency is low. This
project product is suitable for the plate steel, which can realize
continuous welded steel fabric, improved the production efficiency.
2. Adopts two-way 45 ° inclined type straightening machine,
straightening effect is good, all straightening roller can be
adjusted through a hand wheel, convenient adjustment.
3. Longitudinal reinforcement stepping feeding device is convenient
to adjust the longitudinal spacing, suitable for welding for a
variety of specifications of the mesh. (patented)
4. Welding host selection for double impact cylinder, cylinder made
by the company independent research and development, welding
frequency up to 120 times/min, greatly improving the welding
efficiency.
5. The transverse reinforcement automatic feeding system, without
manual, the system consists of PLC program control, which can
realize the continuity of transverse reinforcement accurate
feeding.
6. Finished product mesh collecting device is composed of
shrinkage, mechanical hand, lift orbits, which can realize the
automatic mesh pallet, placed neatly, high production efficiency.
Welding Wire machine parameter
1. Wire material surface pre-treatment
1.1 high shelf pay-off:Put a wire rod, without motor
1.2 Scribble and automatic stop switch: wire out
of the pay-off machine through the steel ring with
a diameter of 200 mm, if a few circle wire
entwined, steel ring that was taken to the other
side, t the bottom of the stroke switch will send
signals, and the entire line emergency stop.
1.3 Repeated bending mechanical shell and
wire ball strong scrubbing device: the wire rod
at least six direction perpendicular(National
initiative)Bending heat treatment to strip iron
oxide on the surface of the wire.
